Overview

The EZ4-S is an ultra-compact manual spin coater designed for space-limited labs, glove box operations and teaching. With an A4-sized footprint and lightweight design, it supports up to 4-inch substrates. Equipped with a brushless DC motor and digital controller, it ensures stable operation. Featuring solvent-resistant HDPE chamber and transparent safety cover, it’s suitable for photoresist coating, organic film and nanomaterial preparation, ideal for micro/nano labs, universities and startup teams.

Core Features

• Ultra-Compact & Portable: Fits in fume hoods, laminar flow hoods and glove boxes. Lightweight for easy transportation between workstations, with streamlined layout for tight spaces.

• Stable Drive & Intuitive Control: 100-9999 rpm brushless DC motor (resolution 1 rpm) runs smoothly with low vibration. Digital controller enables real-time speed monitoring and stepless adjustment, meeting different viscosity material needs.

• Wide Compatibility & Safe Design: Universal vacuum turntable supports 10mm fragments to 4-inch wafers (with optional holders). HDPE chamber resists acids, alkalis and organic solvents, easy to clean. Transparent PC safety cover with lock prevents splashing.

• Cost-Effective & Low Maintenance: Simplified structure without complex programming modules, offering reliable performance at reasonable cost. Easy disassembly for cleaning, low failure rate and minimal maintenance.

Technical Parameters

• Speed range: 100-9999 rpm (resolution 1 rpm)

• Acceleration: 100-9999 rpm/s

• Timing: Max 3000s (resolution 1s)

• Power: AC100-230V, Chinese/English interface optional

• Program: Single/multi-step operation, up to 5 groups of 5-step programs

• Standard holders: 10mm, 25mm, 2-inch vacuum sample holders

Application Scenarios

• Glove box operations for water/oxygen-sensitive materials (perovskite, organic semiconductors)

• University teaching and experimental demonstrations

• Small-scale sample development (chip fragments, <4-inch wafers)

• Space-constrained labs and temporary setups

• Photoresist coating and nanostructured film preparation

Product Advantages

The EZ4-S balances compact size and core performance, saving lab space while supporting diverse scenarios. Intuitive manual control adapts to process exploration, with solvent-resistant and safe design ensuring long-term use. Cost-effective and low-maintenance, it’s a practical tool for teaching, preliminary research and small-batch sample preparation.
